This guide provides a step-by-step walkthrough of Pit Boss grill auger removal and replacement. While we’re using a 700FB model for demonstration, the process is similar across most Pit Boss models with minor variations.
Tools Required for Pit Boss Auger Removal
Before you begin, gather the following tools:
- Phillips head screwdriver (for removing Phillips head screws from the case)
- Allen wrench (to grip auger and slide out)
- Knee-high box or stool (to rest hopper carriage on)
- Replacement auger (if necessary)
- Pipe wrench (for gripping the auger)
Note: Make sure that before performing any maintenance on your pit boss grill first make sure it’s unplugged and cool!
Pit Boss Auger Removal: Step-by-Step Instructions
Easy-to-follow steps on how to perform a Pit Boss full auger removal and replacement.
- Remove 8 Phillips screws from beneath the carriage on the Pit Boss hopper.
- Remove the 2 Phillips head screws from the face of the control board and carefully feed the power cord through hole in the back of the control board.
- Remove the hopper completely by removing the screws on the front and back. Have your box or stool ready to set the hopper on.
- Place the hopper on the stand to keep it from pulling on the power cord.
- A bolt is holding the auger in place. It has a nut on the bottom and an Allen head on top. Use an Allen wrench that matches the screw head size. Next take an Allen head set to size it up, then grip the bottom with a wrench or socket to hold it still while you remove the screws and auger motor.
- Remove the setting screw holding the actual auger in place.
- Grab the little base with a wrench, turn it counterclockwise, and slide it out.
- If you have an auger jam, it will need a strong turn clockwise and a tough pull. You may have to put your back into it. Remove the auger motor then replace it with the new one.
Reinstalling the Pit Boss Auger
Putting everything back together is as simple as doing the steps in reverse order. Ensure all wires are properly connected and the hopper is securely reinstall and locked in place.
Pro Tip for Maintaining Your Pit Boss Auger
We here at Hempen Hill BBQ always have a pair of vice grips on hand for just these occasions. Turn clockwise to remove it, and once removed, use sandpaper to give this Pit Boss auger a good cleaning. Clean the inside of the auger tube, making sure to remove the service door for better access. After that, you should be all set!
Pit Boss Auger Removal and Replacement for Different Models
While this guide uses a 700FB, the process for Pit Boss Austin XL auger removal or Pit Boss Laredo 1000 auger removal is quite similar. The Pit Boss Pro Series auger removal and Pit Boss vertical smoker auger removal may have slight differences. Always refer to your owner’s manual for model-specific instructions.
Conclusion
By following these steps, you can successfully perform Pit Boss auger removal and replacement. Remember to consult your owner’s manual for any model-specific instructions. For a visual guide, check out this YouTube video on ‘Pit Boss auger removal.’
FAQs About Pit Boss Grill Auger Removal
How to remove the auger on a Pit Boss?
1. Safety First: Unplug the grill and let it cool completely.
2. Access the Auger: Remove the hopper and any components obstructing the auger. This typically involves removing screws and disconnecting wires.
3. Detach the Auger: Loosen the set screw holding the auger in place. You may need to use a wrench or vise grips to turn the auger counterclockwise and pull it out.
4. Remove the Motor: If you need to remove the auger motor, disconnect the wires and remove the screws holding it in place.
For detailed instructions and visuals, refer to the “Pit Boss Auger Removal and Replacement: A Step-by-Step Guide” in this article.
How to remove auger from Pit Boss pellet grill?
The process for removing the auger from a Pit Boss pellet grill is similar to the general steps mentioned above. However, there might be slight variations depending on the specific model of your Pit Boss pellet grill.
Always consult your owner’s manual for model-specific instructions before attempting any repairs or maintenance.
How to remove auger from Pit Boss vertical pellet smoker?
Removing the auger from a Pit Boss vertical pellet smoker might require slightly different steps due to the vertical design. Here’s a general outline:
1. Safety First: Unplug the smoker and let it cool down.
2. Access the Auger: Remove the hopper and any panels or components blocking access to the auger.
3. Detach the Auger: Loosen the set screw holding the auger. You might need to use a wrench or vise grips to loosen and remove the auger.
4. Remove the Motor: If necessary, disconnect the wires and remove the screws holding the auger motor in place.
Refer to your Pit Boss vertical pellet smoker’s owner’s manual for detailed instructions and safety precautions.
How to remove jammed auger Pit Boss 700?
A jammed auger can be a bit trickier to remove. Here’s how to approach it:
1. Safety First: Unplug the grill and let it cool completely.
2. Access the Auger: Follow the steps in the main article to remove the hopper and access the auger.
3. Loosen the Auger: If the auger is jammed with pellets or debris, try turning it both clockwise and counterclockwise with a wrench or vise grips to break it free. You may need to apply some force.
4. Remove the Auger: Once the auger is loosened, carefully pull it out of the auger tube.
If you’re unable to remove the jammed auger yourself, it’s best to contact Pit Boss customer support or a qualified technician for assistance.
